Insulation rope description:

Specifications

Ceramic Fiber Rope(insulation rope):

Diameter: 3-50mm;

Tadpole;

Rope with rectangular section is available upon request.

Description:

1.Round braided rope is dense, resilient, high performance ceramic fiber material fabricated from ceramic fiber yarn braided around a core of ceramic fiber rope to form a packing in round section. It is widely used for a broad variety of high temperature gasketing, packing and sealing application.

2. Square braided rope (square packing) is dense, resilient, high performance ceramic fiber material plaited from E-glass, stainless steel wire or high temperature alloy wire inserted ceramic fiber yarn to form a packing in square section.

3.Twisted rope is fabricated from ceramic fiber yarn twisted left hand/right hand together to form a rope of specified diameters ranging from 3 mm to 50 mm, with glass filament, stainless steel wire or high temperature alloy wire inserted to provide high strength at elevated temperature.

Characteristic:

1. Excellent high-temperature strength

2. Excellent electric insulation capability

3. Excellent corrosion resistance to acid oil and steam

4. Low thermal conductivity

5. Excellent thermal insulation capability

Technical Index:

1260 Ceramic Fiber Round Square Rope

Classification Temperature

1260

Product

Ceramic fiber

round braided rope

Ceramic fiber

square braided rope

Code

YXTX-208C1

YXTX-208C2

YXTX-208E1

TXTX-208E2

Service Temperature(°C)

450

1000

450

1000

Basic Material

Ceramic fiber/glass fiber reinforced

Theoretical Density (kg/m3)

500-600

Moisture content(%)

≤2

Delivery state

Roll

Organic Content (%)

≤15
